Lancer 36

The Lancer 36 is an American sailboat that was designed by Bill Lee as a racer-cruiser and first built in 1973.

In 1982 the boat was reintroduced with a fractional rig as the Lancer 36 FR.

Production

The prototype boat, Chutzpah was built the year before Lancer Yachts was formed and was the impetus for starting the company.

Design

The Lancer 36 is a recreational keelboat, built predominantly of fiberglass, with wood trim. It has a masthead sloop rig, a raked stem, a reverse transom, an internally mounted spade-type rudder controlled by a wheel and a fixed fin keel. It displaces 10,500 lb (4,763 kg) and carries 4,000 lb (1,814 kg) of ballast.

The boat has a draft of 6.00 ft (1.83 m) with the standard keel and 4.92 ft (1.50 m) with the optional shoal draft keel.

The boat is fitted with a Japanese Yanmar diesel engine of 27 hp (20 kW) for docking and maneuvering. The fuel tank holds 30 U.S. gallons (110 L; 25 imp gal) and the fresh water tank has a capacity of 50 U.S. gallons (190 L; 42 imp gal).

The design had a number of interior arrangements available. The cruising interior includes sleeping accommodation for six people, with a double "V"-berth around a drop-leaf table in the bow cabin and two aft cabins, each with a double berth. The galley is located on the starboard side just forward of the companionway ladder. The galley is L-shaped and is equipped with a two-burner stove and a double sink. A navigation station is opposite the galley, on the port side. The head is located opposite the galley on the port side and includes a shower.

For sailing downwind the design may be equipped with a symmetrical or asymmetrical spinnaker.
